Exporting Presentation-Ready Renders from Pool Studio, Vip3D and SketchUp
RenderSplash Team7 min read
A plan sells the layout. A rendered still sells the yard.
A top-down plan is correct and useful, and a homeowner still can't read it the way you can. Show them a rendered still of the same design from eye level, with the pool water, the coping and the planting in it, and they stop looking at lines and start looking at their own backyard. Whether that still actually helps you depends on the export, not just the render. A great render saved as a thumbnail, or captured with a toolbar sitting across the bottom of it, looks like a screenshot no matter how good the 3D model underneath it is.
This is a walkthrough of getting a clean, presentation-ready image out of Pool Studio, Vip3D and SketchUp, verified against each vendor's own documentation, plus what to do with the file once you have it.
What to check before you export, whichever tool you're using
Resolution. Aim for at least 1920 x 1080 for anything that might end up on a big screen or a TV in the showroom, and 3840 x 2160 (4K) if you have it to spare. A still exported small and then stretched to fill a homeowner's television looks soft in exactly the moment you need it to look sharp.
No interface visible. Toolbars, panels and navigation controls in the frame are the fastest way to make a photoreal render read as "a screenshot of some software" instead of "our backyard." All three tools below have a way to get a clean, full view before you capture.
Camera height and framing. A SketchUp workflow guide recommends positioning the camera near eye level, about 5 feet 6 inches off the ground, using the Position Camera tool, which reads as a natural, standing viewpoint rather than a drone shot or a dollhouse view (Architizer, "How to Export an Optimized Image From SketchUp"). The same principle carries into Pool Studio and Vip3D: keep the whole feature in frame rather than cropping the far edge of the pool, and use a real, recognizable part of the property (the back of the house, a fence line) as an anchor so the image reads as this yard, not a generic one.
Pool Studio and Vip3D: Photo Mode, not the Export menu
Pool Studio and Vip3D share the same interface for this, since both are Structure Studios products built on the same platform.
There are two different outputs that both get called "exporting a design," and it's worth being precise about which one you want:
The 2D plan. From the Application Button Menu, choosing Export, then 2D Image saves the flat, top-down plan view as a PNG. Choosing AutoCAD instead saves it as a DXF (Structure Studios, "Exporting & Importing"). This is the construction-document view. It is not the rendered photo, and homeowners generally respond to it the way they respond to any plan drawing: correctly, but without much feeling.
The rendered photo. This comes from Photo Mode, a separate feature from the Export menu. Structure Studios' own documentation lays out the steps directly: go to the Presentation Stage and click the Photo Mode button to load a 3D view; move around with standard mouse controls, or Walk mode (Ctrl+W) and Fly mode (Ctrl+F) to compose the shot; then press the Take Photo button, or the P key, to capture it. Resolution is chosen from a drop-down before you shoot, with 1080p, 2K, 4K and 8K all available (2K is the default), plus square and vertical crops sized for social posts (Structure Studios, "Photo Mode"). For a presentation you're building around, choose 4K.
Vip3D's version of Photo Mode adds controls Pool Studio doesn't have: a camera lens (mm) slider, an accurate focus mode for real depth of field, and effects like bloom and lens flare on top of the professional camera options (Structure Studios, "Photo Mode"). Vip3D's product page also highlights path tracing built to show "reflections move, shadows shift, and light refract in translucent water and glass" rather than approximating it (Structure Studios, Vip3D product page). Path-traced light takes longer to render than a quick preview, so if you have Vip3D available for a hero shot with water, glass or heavy reflection in it, that's the tool to reach for and budget the extra render time for the one image you're going to build the whole presentation around.
One honest caveat: Structure Studios' interface changes between versions, and a menu label that's exactly right in one release can shift in the next. If a button isn't where this describes, the reliable fallback is Structure Studios' own help center at help.structurestudios.com, searched for your installed version.
SketchUp: File > Export > 2D Graphic
SketchUp's export path is documented directly by Trimble and has stayed the same across recent desktop versions:
- Set up your shot first: camera position, Shadow Settings for the time of day and year you want the shadows to represent, and your visual style.
- Go to File > Export > 2D Graphic.
- Choose a save location and a file name.
- From the Export Type drop-down, pick a raster format: JPEG, PNG, TIFF or BMP.
- Click Options.
- Uncheck Use View Size if you want a specific pixel size rather than a 1:1 export of your window; enter a width (1920 for 1080p, 3840 for 4K) and the height adjusts to match your window's proportions automatically.
- Leave Anti-alias checked. It's on by default and it's what keeps edges from looking jagged.
- PNG and TIFF offer a Transparent Background option, useful if the image is headed into a compositing or video workflow rather than straight to a client.
- Click OK, then Export (SketchUp Help, "Importing and Exporting Image Files").
A width around 4,000 pixels at 300 pixels per inch is a reasonable target if you also want the same file to hold up printed at large format, not just on a screen (Architizer).
Two things worth knowing before you rely on this workflow. First, SketchUp's own vector export to PDF or EPS can lose or change model details, so Trimble's own guidance is to send the model to LayOut and print from there instead if you need a true vector or paginated document, rather than exporting a vector PDF directly from SketchUp itself (SketchUp Help). Second, SketchUp for iPad only exports PNG, with no documented resolution controls beyond that, and SketchUp for Web (the free browser version) doesn't have its image export options fully documented by Trimble at all (SketchUp Help, "Importing and Exporting" (iPad)). If you need a specific pixel size for a client presentation, SketchUp Pro on desktop is the version built for it.
It's also worth naming plainly what SketchUp's own export is and isn't. The 2D Graphic export gives you a clean, shaded, materials-visible view. It's not a photoreal render the way Pool Studio's or Vip3D's Photo Mode output is, and it isn't trying to be. Extensions like V-Ray, Enscape and Lumion add photorealistic rendering inside SketchUp, each with its own separate export process. If your presentation needs the shaded SketchUp look, export it as above. If it needs to look like a photograph, that's a rendering extension's job, not the base export.
What to do with the file once you have it
JPEG is the right default for a presentation still: it opens on any device, uploads fast, and at high quality the compression isn't visible on a screen at the distance a homeowner is actually viewing it from. Reach for PNG when the image needs a transparent background, is going into a video or compositing workflow, or will be printed large. An 8K capture is rarely necessary for a sales meeting; 4K at high JPEG quality looks the same to a homeowner standing in a living room as 8K does, and it's a smaller file to email or open on a phone.
If you're already exporting clean, full-resolution stills from any of these tools, the natural next step is turning them into something that moves. RenderSplash takes one to twelve of the rendered stills you already have, plus an optional 2D plan in the same PNG, JPG, PDF or DXF formats Pool Studio, Vip3D and SketchUp all export, and turns them into a video you can play at the kitchen table. Nothing about your export workflow has to change to use it; it starts from the same files you'd otherwise attach to an email.
The short version
Get the interface out of the frame, capture at 4K where you can, and know which export you're actually reaching for: Photo Mode for a rendered still in Structure Studios' tools, the Export menu only for the flat plan. In SketchUp, File > Export > 2D Graphic gets you a clean shaded image, not a photoreal one, unless a rendering extension is doing the work underneath it. None of this is complicated once you know where to look. It's just easy to get backwards the first few times, and the difference shows up exactly when you can least afford it, on a homeowner's television, mid-pitch.
